Description:
- Material: polyester filter bag are made of 100% filament polyester fiber.
- Feature:
1. Operation temperature 150 Deg c,
2. the max surge is 150 deg c.
3. good anti-acid, good anti-alkali ,good hydrolysis stability
4. Mean Air Permeability: 10-15 m3/m2/min@12.7mmH2O
Available Finish: singed, calendar, PTFE membrane, W/O
- Advantage:
Breaking Elongation is less than 20% for MD and 40% for CMD, low dry shrinkage, can work well in the 130 deg C. the material is cheaper than other material, so widely used in a lot of bag house system.
Technical Data:
| Thickness | 1.70mm |
| Mean Air Permeability | 10-15 m3 /m2/ min@12.7mmH2O |
| Breaking Strength-MD | 900 N / 5cm |
| Breaking Strength-CMD | 1300 N / 5cm |
| Breaking Elongation( N/5cm)-MD | 20% |
| Breaking Elongation( N/5cm)-CMD | 40% |
| Dry Shrinkage MD | 1.5 % |
| Dry Shrinkage CMD | 1.5 % |
| Operating Temperatures | 130 deg C |
| Recommended Maximum Continuous | 130 deg C |
| Recommended Maximum Surge | 150 deg C |
- Application
Polyester filter bag are widely used in Cement Industry, Chemical Industry, Aluminum Industry, Powder Industry, etc.
