Description:
- Material: Antistatic polyester bag are made of 100% filament polyester fiber with antistatic scrim..
- Feature:
1. Operation temperature 150 Deg c,
2. the max surge is 150 deg c.
3. good anti-acid, good anti-alkali ,good hydrolysis stability
4. Mean Air Permeability: 10-15 m3/m2/min@12.7mmH2O
- Available Finish: singed, calendar, PTFE membrane, W/O
- Advantage:
Breaking Elongation is less than 20% for MD and 40% for CMD, low dry shrinkage, can work well in the 130 deg C. the material is cheaper than other material, so widely used in a lot of bag house system. 1.
Technical Data:
- 1. Needle puched felt
- 2. Woven filtration fabric
- 3. Filter bags
- 4. Filter cages
- 5. Filter tubing automatic production line
| Specs And Features | |||||
| Material | Polyester/PET antistatic scrim | Thickness | 1.9 | ||
| Weight(g/sqm) | 500 | Density(g/cm³) | 1.38 | Air Permeability(m³/m²/min) | 12~16 |
| Warp Tensile Strength (N/5x20cm) |
>1000 | Weft Tensile Strenght (N/5x20cm) |
>1300 | Moisture Regain (20℃ And 65% r. humidity) |
0.10% |
| Warp Elongation(%) | <30 | Weft Elongation(%) | <50 | Support Combustion | Yes |
| Continuous Dry Heat Operation(℃) |
135 | Continuous Moist Heat Operation(℃) |
94 | Max Short Dry Heat Surge(Short Term)(℃) |
150 |
| Biological(Mildew, Bacteria) | fair | Alkalis | fair | Mineral Acids | fair |
| Organic Acids | fair | Oxidising Agents | good | Organic Solvents | good |
| Finishing | Singeing-calendering-heat setting | ||||
| Product Applications | Chemical/ Steel/Waste Incineration/Thermoelectricity/Construction Material | ||||
| Usage | Air Filter | ||||
| Type | Filter Felt | ||||
| Specialized in supplying | |||||
|
|
|||||
- Application
polyester filter bag are widely used in cement industry, chemical industry, Aluminum industry , powder industry ,etc.
